MIL-D-22233D
* 5.1.2 Commercial.
with ASTM D
Material shall be packaged in accordance
3951.
* 5.2 Packing.
Packing shall be level A, B, or Commercial as specified (see
6.2).
5.2.1 Level A. The drill rods, couplings, shanks, extractors and bits
shall be packed in boxes conforming to PPP-B-621, class 2. Items of like
description shall be packed together. The boxes for drill rods shall be
modified to include full double ends, with the inner pieces positioned
vertically and the outer pieces horizontally. The minimum thickness of the end
pieces shall be governed by the minimum thickness of ends specified for styles 2
or 2-1/2 boxes of the above specification. The contents shall be cushioned,
blocked, and braced to prevent movement within the boxes.
5.2.2 Level B. The drill rods, couplings, shanks, extractors, and bits
shall be packed as specified for level A, except that the boxes shall conform
to PPP-B-621, class 1.
* 5.2.3
Commercial. Material shall be packed in accordance with ASTM D 3951.
* 5.3 Marking.
Marking shall be in accordance with MIL-STD-129.
6.
NOTES
(This section contains information of a general or explanatory nature that
may be helpful, but is not mandatory.)
6.1 Intended use. The components covered by this specification, drill rod,
coupling, shank, extractor, and replaceable rock bit are for equipping drifter
drills to drill holes in rock formations.
6.2 Acquisition documents. Acquisition documents should specify the
following:
a. Title, number, and date of this specification.
b. Type, styles, and size required (see 1.2).
c. Issue of DODISS to be cited in the solicitation, and if required, the
specific issue of individual documents referenced (see 2.1.1 and
2.2).
d. Level of preservation and level of packing required (see 5.1 and
5.2).
* 6.3 Part or identifying number (PIN). The PIN to be used for drill string
components covered by this specification are created as follows:
6
